Hydro-Gear T2-BAED-2X3B-1NX1 T2 Click to zoom

Hydro-Gear T2-BAED-2X3B-1NX1 T2 Hydrostatic Transaxle

MPN T2-BAED-2X3B-1NX1

Free shippingIn stockHydrostatic Transaxle

Overview

Hydro-Gear T2-BAED-2X3B-1NX1 is a genuine Hydro-Gear T2 hydrostatic transaxle. The T2 is a Hydro-Gear residential integrated hydrostatic transaxle with die-cast aluminum housings and a maintenance-free design, made for the lawn and garden industry.

Order by the full model number on the Hydro-Gear label (T2-BAED-2X3B-1NX1). Hydro-Gear builds each model to an OEM specification and advises against substituting a different model, so match every character.

More on this series: How to find your Hydro-Gear part number · Shop all Hydro-Gear parts

Specifications

Brand Hydro-Gear (genuine)
Model / part number T2-BAED-2X3B-1NX1
Series T2
Type Hydrostatic transaxle
Pump / motor displacement (series spec) 8 cc variable pump / 10.2 cc motor
Input speed (series spec) 1,800–3,000 rpm
Axle (series spec) 3/4 in
Brake (series spec) External disc
Weight on tires (series spec) 540 lb (most configurations)
Unit weight (series spec) 28 lb
Fluid 20W-50 engine oil (factory filled)
Filter Internal (replaced only during internal repair)

Service notes

  • Hydro-Gear's manual says the T2 is factory filled and sealed and does not require oil maintenance; an oil change requires removing the transaxle from the vehicle.
  • Oil: 20W-50 engine oil, about 65–70 fl oz depending on the housing.
  • After installing, purge air from the system following Hydro-Gear's procedure: wheels off the ground, engine at 3/4 to full throttle, cycle forward/reverse 5–6 times with the bypass open, then 5–6 times closed, and top up the oil.

Shipping

  • Free shipping (lower 48).

Frequently asked questions

Where do I find my Hydro-Gear model number?

On the Hydro-Gear label on the unit (on the transaxle). Current numbers look like T2-AABC-2X1A-1CXX. See how to find your Hydro-Gear part number.

Can I use a different model that looks the same?

Hydro-Gear strongly discourages using any model not originally specified by the mower maker; similar-looking units can differ internally. Order the exact number on your label.
